PRODUCTS

>> MILLING & GRINDING

ER Spring Collet Chuck System

Collect Holder with Cat-Shank
ER Spring Collet Chuck System
ER Spring Collet Chuck System

Order No.
Collect Type
Taper
D
L
G
Weight Kgs
Code No.
V-870
ER16
CAT30
28
2"
1/2"-13
0.8
3034-301
V-871
ER16
CAT40
28
3"
5/8"-11
1.1
3035-301
V-872 ER20
34
3"
1.2
3035-302
V-873 ER25
42
2-1/2"
1.2
3035-303
V-874 ER32
50
2-1/2"
1.2
3035-304
V-875 ER40
63
3"
1.5
3035-305
V-876 ER40 CAT 50
63
3-1/2"
1/8"
4
3036-301
ER Spring Collet Chuck System

COLLET CHUCK KIT WITH CAT-SHANK
INCLUDING SHANK, FULL SET OF COLLET, WRENCH AND CASE

  1. ER16, ER20, ER25 PACKED IN WOODEN BOX.
  2. ER32,ER40, PACKED IN PLASTIC BOX.
  3. PACKAGE INCLUDING: CHUCK, COLLET, WRENCH, BOX.



ORDER NO.

COLLET TYPE

CAT TAPER

SET RANGE

SETPCS

WEIGHTKGS

CODE NO.

V-878

ER16

CAT40-3"L

1.0-10

10

2.3

3035-401

V-879

ER20

CAT40-3"L

2.0-13

12

2.5

3035-402

V-880

ER25

CAT40-2 1/2"L

2.0-16

15

3

3035-403

V-881

CAT 40-2 1/2"L

4.0-16

7

2.8

3035-404

V-882



CAT40-2 1/2"L

3.0-20

18

5.2

3035-405

V-883

ER32

CAT 40-2 1/2"L

4.0-20

11

4.2

3035-406

V-884

CAT40-2 1/2"L

6.0-20

6

3.8

3035-407

V-885

ER40

CAT40-3"L

4.0-26

23

8.9

3035-408

V-886

CAT40-3"L

4.0-26

15

7.6

3035-409

V-887

CAT40-3"L

6.0-25

7

6

3035-410

V-888

ER40

CAT50-3 1/2"L

4.0-26

23

11.2

3036-401

V-889

CAT50-3 1/2"L

4.0-26

15

9.8

3036-402

V-890

CAT50-3 1/2"L

6.0-25

7

8.3

3036-403
