Integated Type Keyless Drill Chucks


Integated Type Keyless Drill Chucks




Integated Type Keyless Drill Chucks

Standard Acces.

The main-shaft is of integrated type, which is much more superior than the traditional design.

The major features are as follows.


* Extremely rigid construction.
* The accumulative tolerance can be reduced to a minimum, since the tradirtional mechanism requiring an ARBOR to connect tthe Drill Chucks which will generate the accumulative tolerances. The integrated type keyless Drill Chuck is deisgned to slove this problem totally.
* Prevent the Drill Chucks from falling out.
* Extermely safe in operation.

Item No.
d
mm
L
mm
Max
Tolerance
mm
Torque
kgf-cm
INT-8
3
25
0.05
160
6
8
30
INT-10
3
25
0.05
260

6

10
30
INT-13
5
30
0.05
400

10

13
25
INT-16
5
25
0.05
480

10

16
30



Order No.

Clamping Capacity

Female Taper
DIN or Jacobs
STD
Outer Ø /mm
Length
Weight
Kgs
Code NO.
Ø mm
Ø inch
Open B mm
Closed A mm
INT-8-MT-2 0-8
0-5/16"
MT-2

35
140
148
0.8
3301-030
INT-8-JC-20 0-8
0-5/16"
JC-20

35
124
132
0.8
3301-031
INT-8-BT30 0.5-8
1/64"-1/8"
BT30

35
1
3301-070
INT-8-BT-40 0.5-8
1/64-1/8"
BT40

51.5
1.5
3301-072
INT-8-NT40 0.5-8
1/64"-1/8"
NT30

51.5
0.8
3301-080
INT-13-R8 0.5-8
1/64"-1/8"
NT40

51.5
1.3
3301-081
INT-13-MT2 1-13
0-1/2"
R8

51.5
183
175
1.5
3301-032
INT-13-MT-3 1-13
0-1/2"
MT-2

51.5
184
172
1.3
3301-082
INT-13-MT4 1-13
0-1/2"
MT-3

51.5
182
194
1.4
3301-033
INT-13-JC--20 1-13
0-1/2"
MT-4

51.5
182
150
1.8
3301-035
INT-13-JC-25 1-13
0-1/2"
JC-20

51.5
138
150
1.4
3301-036
INT-13-JC-32 1-13
0-1/2"
JC-25

51.5
138
150
1.6
3301-037
INT-13-NT-30 1-13
0-1/2"
JC-32

51.5
138
150
1.8
3301-038
INT-13-NT40 1-13
0-1/2"
NT-30

51.5
138
150
1.4
3301-039
INT-13-BT-30 0.5-13
1/64"-1/2"
NT-40
DIN 2080
51.5
98
109
1.8
3301-71
INT-13-BT-40 1-13 0-1/2"
BT30
51.5

1.4
3301-040
INT-13-BT50 1-13 0-1/2"
BT-40
ISO
51.5
98
109
2
3301-041
INT-13-NT-50 1-13 1/8"-5/8"
BT-50
ISO
51.5
109
120
4.7
3301-059
INT-16-R8 3-16 1/8"-5/8"
R8
51.5
4.22
3301-042
INT-16-MT3 3-16 1/8"-5/8"
MT3
58
188
202
1.9
3301-043
INT-16-MT4 3-16 1/8"-5/8"
MT4
58
188
202
1.9
3301-044
INT-16-JC-20 3-16 1/8"-5/8"
JC-20
58
188
202
1.9
3301-045
INT-16-JC-25 3-16 1/8"-5/8"
JC-25
58
140
155
2
3301-046
INT-16-JC-32 3-16 1/8"-5/8"
JC-32
58
150
165
1.8
3301-047
INT-16-NT40 3-16 1/8"-5/8"
NT-40
ISO
58
116
165
1.7
3301-049
INT-16-BT40 3-16 1/8"-5/8"
BT-40
ISO
58
116
130
2.2
3301-050
INT-16-BT-50 3-16 1/8"-5/8"
BT-50

58
126
130
2.6
3301-051
INT-16-NT50 3-16 1/8"-5/8"
NT-50

58

140
2.5
3301-056
